Cisco 6921 Administration Guide

F-5
Cisco Unified IP Phone 6921, 6941, 6945, and 6961 Administration Guide for Cisco Unified Communications Manager 8.6 (SCCP and SIP)
OL-24567-01
Appendix
ADA Non-Lockable Wall Mount Kit for 6900 Series
Figure F-5 Attach Phone Bracket
Step 3 Attach the cables.
a. Attach the Ethernet cable to the 10/100 SW network port and wall jack.
b. (Optional) If you are connecting a network device (such as a computer) to the phone, attach the cable
to the 10/100 PC access port.
c. (Optional) If you are using an external power supply, plug the power cord into the phone and dress
the cord by clipping it into the clips incorporated into the phone body next to the 10/100 PC port.
The following figure shows the cable attachment.
274937
Screw holes
Slot for
mounting tabs
