Chapter 2 Route Switch Processors and Supervisor Engines
Overview
WS-SUP720-3B • Two Gigabit Ethernet uplink ports: port 1 supports a 1-Gbps SFP
module; port 2 is configurable with either a 1-Gbps SFP module
or a 10/100/1000-Mbps RJ-45 connector
• Integrated 720-Gbps switch fabric
• PFC3B and MSFC3 with 2-MB NVRAM, 512-MB DRAM, and
64-MB bootflash (see note below)
• Two CompactFlash Type II slots
• Requires larger power supplies and a high-speed fan tray
• QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t
WS-SUP720-3BXL • Two Ethernet uplink ports: port 1 supports a 1-Gbps SFP
module; port 2 is configurable with either a 1-Gbps SFP module
or a 10/100/1000-Mbps RJ-45 connector
• Integrated 720-Gbps switch fabric
• PFC3BXL and MSFC3 with 2-MB NVRAM, 1-GB DRAM, and
64-MB bootflash; high-capacity PFC3BXL allows routing and
forwarding processes to be offloaded from the supervisor engine
to the PFC (see note below)
• Two CompactFlash Type II slots
• Requires larger power supplies and a high-speed fan tray
• QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t
Note A CompactFlash (CF) adapter with 512-MB bootflash is available for Sup720 modules in
Release 12.2(18)SXF and later releases. Use the Cisco part number CF-ADAPTER= for
ordering.
Supervisor Engine 32
WS-SUP32-GE-3B • Nine Gigabit Ethernet uplink ports: eight SFP modules and one
RJ-45 10/100/1000-Mbps connector
• Integrated 32-Gbps switch fabric
• PFC3B and MSFC2 daughter cards (see notes below)
• QoS port architecture (Rx/Tx): 1p3q8t/1p3q8t
WS-SUP32-10GE-3B • Two 10-Gigabit Ethernet ports (XENPAKs) and one
10/100/1000-Mbps connector
• Integrated 32-Gbps switch fabric
• PFC3B and MSFC2 daughter cards (see notes below)
• QoS port architecture (Rx/Tx): 1p3q8t/1p3q8t
Note To run Release 12.2SRB, the Sup32 requires a minimum of 512-MB DRAM.
Note A CF adapter with 512-MB bootflash is available for Sup32 modules in Release 12.2(18)SXF
and later releases. Use the Cisco part number CF-ADAPTER= for ordering.
Supervisor Engine 2
Table 2-1 Route Switch Processor and Supervisor Engine Configurations (continued)
Product Number Description

Cisco 7600 Series Specifications

General

Category	Network Router
Port Density	Varies by module
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet
Redundancy	Power supplies
Power Supply	AC or DC, Redundant options available
Operating System	Cisco IOS XR
Management	CLI, SNMP
Form Factor	Modular
Dimensions	Varies by chassis model
Weight	Varies by chassis model and configuration
Chassis Slots	6, 9, or 13
