Cisco 7600 Series Guide

2-6
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide
OL-10100-04
Chapter 2 Route Switch Processors and Supervisor Engines
Route Switch Processor 720
Route Switch Processor 720
This section describes the Route Switch Processor 720 (RSP720). The Cisco 7600 RSP720 consists of a
full-size board and two integrated daughter cards: the MSFC4 and a PFC3C or PFC3CXL. The RSP720
has an integrated switch fabric that interconnects all of the line cards in the Cisco
7600 router with
point-to-point 20-Gbps full-duplex serial channels.
Note • Cisco IOS Release 12.2SRB and later releases support the RSP720; earlier releases do not.
The RSP720 is supported on all Cisco 7600 routers (including enhanced chassis) except the Cisco
7603 and the Cisco OSR-7609.
• Cisco IOS Release 12.2SRC and later releases support an RSP720 that has 10GE uplinks
(RSP720-3C-10GE and RSP720-3CXL-10GE). See the
“RSP720 with 10GE Uplink Ports” section
on page 2-8 for more information.
Figure 2-1 shows the RSP720-3C-GE front panel, which is the same as the RSP720-3CXL-GE front
panel. See Table 2-2 and Table 2-3 for information about the front-panel controls and LEDs.
WS-X6K-S2-MSFC2 • Two dual-port 1000BASE-X GBIC uplinks, 16-MB bootflash,
128-MB DRAM on supervisor engine and 128
MB on MSFC2
• PFC2 and MSFC2
• Fabric enabled to support optional switch fabric module (SFM2)
• QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t
WS-X6K-S2U-MSFC2 • Two dual-port 1000BASE-X GBIC uplinks, 32-MB bootflash,
256-MB DRAM on supervisor engine and 256
MB on MSFC2
• PFC2 and MSFC2
• Fabric enabled to support optional SFM2
• QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t
WS-X6K-S2-PFC2 • Two dual-port 1000BASE-X GBIC uplinks
• PFC2; fabric enabled, supports optional SFM2
• QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t
WS-X6500-SFM2 • (Optional) SFM2
Note The Sup2 is not supported in Cisco IOS Release 12.2SRA and later releases.
Table 2-1 Route Switch Processor and Supervisor Engine Configurations (continued)
Product Number Description

Cisco 7600 Series Specifications

General

Category	Network Router
Port Density	Varies by module
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet
Redundancy	Power supplies
Power Supply	AC or DC, Redundant options available
Operating System	Cisco IOS XR
Management	CLI, SNMP
Form Factor	Modular
Dimensions	Varies by chassis model
Weight	Varies by chassis model and configuration
Chassis Slots	6, 9, or 13
