Soft Key Legend
Your Cisco Unified IP phone is equipped with soft keys that point to feature options displayed along the bottom of the LCD
screen. Soft keys change according to the state of the phone.
The following is a comprehensive list of soft keys offered on the Cisco Unified IP Phone 7931G. Functionality varies according
to your system configuration.
4
Hold button Places calls on hold. Press the line button, flashing green or red, to retrieve a call on
hold.
5
Transfer button Connects a call to another number.
6
Redial button Connects to the last dialed number.
7
Keypad Functions like a traditional telephone keypad.
8
Mute button Toggles mute on and off.
9
Volume button Increases or decreases handset, headset, ringer, or speakerphone volume.
10
Speaker button Toggles the speaker on and off.
11
Handset Functions like a traditional handset.
12
Handset indicator light Flashes for an incoming call and remains on when there is a message waiting.
13
LCD screen Displays information such as line/call status, phone number, and soft key tabs.
14
Cisco Unified IP phone model
type
Shows the Cisco Unified IP phone model number.
15
4-way navigation pad and Select
button
Scrolls through text and selects features that are displayed on the LCD screen. View
directory numbers, lines, and features assigned to each line button. The Select button is
at the center of the navigation pad.
Soft Key Function
<< or >> Use these soft keys to move the cursor to the left or right. Moving the cursor to the left
can erase information that you have entered.
Acct Consult your administrator on the use of this soft key.
Callback Notifies callers that the called line is free.
Cancel Cancels the last selection.
CFwdALL Forwards all calls.
Clear Clears directory history.
Confrn Connects callers to a conference call.
Delete Deletes current number.
Dial Dials the displayed number.
Directories Provides access to phone directories.
DND Activates the Do-Not-Disturb feature.
Down Decreases the LCD screen contrast.
EditDial Selects a number and activates the cursor for editing.
EndCall Ends the current call.
Exit Exits from the current selection or screen.
Flash Provides hookflash functionality for three-way calling and call-waiting services
provided by the PSTN or Centrex service.
Feature Description
