Page #8 background imageLoading...
Page #8 background image
New and Changed for Firmware Release 11.3(1)
New and Changed SectionsRevision
Auto Provision Your Phone with Short Activation
Code, on page 10
Added new task to support Auto Provisioning with
Short Activation Code.
Find Information About Your Phone, on page 23Updated an existing task to support display UDI
feature on phone screen
Get More Information When Your Phone Displays a
Provisioning Failure Message, on page 29
Added a task to support Serviceability Enhancement
Messages for Provisioning Failure
New and Changed for Firmware Release 11.2(3)SR1
New or Changed SectionsRevisions
Onboard Your Phone with Activation Code, on page
9
Added a new task about getting your phone onboard
with the activation code
Phone Setup
Your administrator sets up your phone and connects it to the network. If your phone is not set up and connected,
contact your administrator for instructions.
Connect to the Network
You need to connect the phone to the network.
Wired network connection—All wired network connections use one of the following:
PoE deployment: Connect the phone to the Cisco IP Conference Phone 8832 PoE Injector
(CP-8832-POE) and connect the injector to the network with an Ethernet cable.
Non-PoE deployment: Connect the phone to the Cisco IP Conference Phone 8832 Non-PoE
Ethernet Injector (CP-8832-ETH or CP-8832-ETH-WW). Then, connect the injector to the network
with an Ethernet cable and plug the injector into the electric outlet.
CP-8832-ETH and CP-8832-PWR are for North America. CP-8832-ETH-WW and CP-8832-PWR-WW are
for other locations.
Note
Your Phone
8
Your Phone
New and Changed for Firmware Release 11.3(1)

Other manuals for Cisco 8832

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco 8832 and is the answer not in the manual?

Cisco 8832 Specifications

General IconGeneral
Control typeButtons
Display typeLCD
Product typeIP conference phone
Voice codecsG.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
CertificationCE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product colorCharcoal
Frequency range100 - 20000 Hz
Built-in displayYes
Display diagonal3.9 \
Languages supportARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution480 x 128 pixels
Security algorithmsEAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates10, 100 Mbit/s
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables includedUSB
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 95 %
Operating relative humidity (H-H)10 - 90 %
USB connector typeUSB Type-C
RJ-45 ports quantity1
Weight and Dimensions IconWeight and Dimensions
Width278 mm
Height61 mm
Weight1850 g
