Configuring Modular QoS Service Packet Classification and Marking on Cisco ASR 9000 Series Routers
How to Configure Modular QoS Packet Classification and Marking on Cisco ASR 9000 Series Routers
QC-25
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters global configuration mode.
Step 2
interface
type
interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# interface
gigabitethernet 0/1/0/9
Enters interface configuration mode and configures an
interface.
Step 3
service-policy {input | output}
policy-map
Example:
RP/0/RSP0/CPU0:router(config-if)#
service-policy output policy1
Attaches a policy map to an input or output interface to be
used as the service policy for that interface.
• In this example, the traffic policy evaluates all traffic
leaving that interface.
Step 4
end
or
commit
Example:
RP/0/RSP0/CPU0:router(config-if)# end
or
RP/0/RSP0/CPU0:router(config-if)# commit
Saves configuration changes.
• When you issue the end command, the system prompts
you to commit changes:
Uncommitted changes found, commit them before
exiting(yes/no/cancel)?
[cancel]:
–
Entering yes saves configuration changes to the
running configuration file, exits the configuration
session, and returns the router to EXEC mode.
–
Entering no exits the configuration session and
returns the router to EXEC mode without
committing the configuration changes.
–
Entering cancel leaves the router in the current
configuration session without exiting or
committing the configuration changes.
Use the commit command to save the configuration
changes to the running configuration file and remain within
the configuration session.
Step 5
show policy-map interface
type
interface-path-id
[input | output]
Example:
RP/0/RSP0/CPU0:router# show policy-map
interface gigabitethernet 0/1/0/9
(Optional) Displays statistics for the policy on the specified
interface.
