Configuring Modular QoS Congestion Avoidance on Cisco ASR 9000 Series Routers
How to Configure Modular QoS Congestion Avoidance on Cisco ASR 9000 Series Routers
QC-80
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
SUMMARY STEPS
1. configure
2. policy-map policy-name
3. class class-name
4. random-detect dscp dscp-value min-threshold [units] max-threshold [units]
5. bandwidth {bandwidth [units] | percent value}
or
bandwidth remaining [percent value | ratio ratio-value]
6. shape average {percent | value [units]}
7. queue-limit value [units]
8. exit
9. interface type interface-path-id
10. service-policy {input | output} policy-map
11. end
or
commit
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters global configuration mode.
Step 2
policy-map
policy-name
Example:
RP/0/RSP0/CPU0:router(config)# policy-map
policy1
Enters policy map configuration mode.
• Creates or modifies a policy map that can be attached to
one or more interfaces to specify a service policy.
Step 3
class
class-name
Example:
RP/0/RSP0/CPU0:router(config-pmap)# class
class1
Enters policy map class configuration mode.
• Specifies the name of the class whose policy you want
to create or change.
