Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
How to Configure Channelized SONET/SDH
HC-328
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
5. sts number
6. mode mode
7. width number
8. root
9. controller controllerName instance
10. mode mode
11. root
12. controller t1 interface-path-id
13. channel-group number
14. timeslots num1:num2:num3:num4
or
timeslots range1-range2
15. show configuration
16. root
17. interface serial interface-path-id
18. encapsulation {frame-relay | hdlc | ppp}
19. ipv4 ip-address mask
20. no shutdown
21. end
or
commit
22. show
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters global configuration mode.
Step 2
controller sonet interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# controller
sonet 0/1/1/0
Enters SONET controller configuration submode and specifies the
SONET controller name and interface-path-id with the
rack/slot/module/port notation.
