Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
How to Configure Channelized SONET/SDH
HC-344
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
Step 10
timeslots num1:num2:num3:num4
or
timeslots range1-range2
Example:
RP/0/RSP0/CPU0:router(config-t1-channel_g
roup)# timeslots 1:3:7:9
RP/0/RSP0/CPU0:router(config-t1-channel_g
roup)# timeslots 1-12
Specifies time slots for the interface by number with the
num1:num2:num3:num4 notation, or by range with the
range1-range2 notation.
Step 11
show configuration
Example:
RP/0/RSP0/CPU0:router(config-t1-channel_g
roup)# show configuration
Displays the contents of uncommitted configuration.
Step 12
root
Example:
RP/0/RSP0/CPU0:router(config-t3)# root
Exits to global configuration mode.
Step 13
interface serial interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# interface
serial 0/1/1/0/0/0:0
Specifies the complete interface number with the
rack/slot/module/port/T3Num/T1num:instance notation.
Step 14
encapsulation {frame-relay | hdlc | ppp}
Example:
RP/0/RSP0/CPU0:router(config-if)#
encapsulation frame-relay
Specifies the encapsulation type with the one of the following
keywords:
• frame-relay—Frame Relay network protocol
• hdlc—High-level Data Link Control (HDLC) synchronous
protocol
• ppp—Point-to-Point Protocol
Step 15
ipv4 ip-address mask
Example:
RP/0/RSP0/CPU0:router(config-if)# ip
address 10.10.10.10 255.255.255.255
Assigns an IP address and subnet mask to the interface.
Step 16
no shutdown
Example:
RP/0/RSP0/CPU0:router(config-if)# no
shutdown
Removes the shutdown configuration.
Note Removal of the shutdown configuration eliminates the
forced administrative down on the interface, enabling it to
move to an up or down state (assuming that the parent
SONET layer is not configured administratively down).
Command or Action Purpose
