Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
How to Configure Channelized SONET/SDH
HC-351
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
Step 6
mode tug3
Example:
RP/0/0/CPU0:router(config-auPath)# mode
tug3
Sets the mode of interface at the AU level. Currently only TUG3 is
supported.
Step 7
width number
Example:
RP/0/0/CPU0:router(config-auPath)# width
3
Configures the number of the AU streams.
Step 8
tug3 number
Example:
RP/0/0/CPU0:router(config-auPath)#tug3 1
Specifies the Tributary Unit Group (TUG) number and enters the
config-tug3Path mode. The range is 1 to 3.
Step 9
mode mode
Example:
RP/0/0/CPU0:router(config-tug3Path)# mode
e3
Sets the mode of interface at the tug3 level. The modes are:
• c11—TUG-3 path carrying TU-11
• c11-t1—TUG-3 path carrying TU-11 to T1
• c12—TUG-3 path carrying TU-12
• c12-e1—TUG-3 path carrying TU-12 to E1
• e3—TUG-3 path carrying E3
• t3—TUG-3 path carrying T3
Note The 1-Port Channelized OC-48/STM-16 SPA only supports
the e3 and t3 options.
Step 10
root
Example:
RP/0/0/CPU0:router(config-tug3Path)# root
Exits to global configuration mode.
Step 11
controller name instance
Example:
RP/0/0/CPU0:router(config)# controller e3
0/1/1/0/0/0
Enters controller configuration submode and specifies the
controller name and instance identifier with the
rack/slot/module/port/name/instance notation. The controller
names are:
• e3—TUG3 path carrying E3
• t3—TUG3 path carrying T3
• e1—channelized E1 port
Note In this step, you can create an E3 or T3 controller and add
T1 channels under the T3 controller as shown in Step 14,
or you can create a channelized E1 port at this point.
Note E1 is not supported on the 1-Port Channelized
OC-48/STM-16 SPA.
Command or Action Purpose
