Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
Information About Configuring Channelized SONET/SDH
HC-321
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
Figure 23 shows an example of some SONET controller configuration combinations.
Note The 1-Port Channelized OC-48/STM-16 SPA on the Cisco ASR 9000 Series Router does not support
VTGs.
Figure 23 SONET Controller Configuration Combinations
STS 3
SONET
Controller
STS 2
STS 1
Clear Channel
T3
210873
VTG 1
VTG 2
VTG 3
VTG 4
VTG 5
VTG 6
VTG 7
To Next Page
