Cisco Aironet 1572EC - Page 17

Required Quantity
(#Ports)
TypeGainFrequency BandProduct ID
4 (1)Omnidirectional6 / 8 dBi2.4 / 5 GHzAIR-ANT2568VG-N
4 (1)Omnidirectional4 / 7 dBi2.4 / 5 GHzAIR-ANT2547VG-N
1 (3)Directional 120x30°8 / 8 dBi2.4 / 5 GHzAIR-ANT2588P3M-N=
1 (4)Directional 30x30°13/13 dBi2.4 / 5 GHzAIR-ANT2513P4M-N=
2 (1)Omnidirectional5 dBi2.4 GHzAIR-ANT2450V-N=
2 (1)Omnidirectional8 dBi2.4 GHzAIR-ANT2480V-N=
1 (2)Directional 30x30°13 dBi2.4 GHzAIR-ANT2413P2M-N=
2 (1)Omnidirectional8 dBi5 GHzAIR-ANT5180V-N=
1 (2)Directional 30x30°14 dBi5 GHzAIR-ANT5114P2M-N=
New Antenna AIR-ANT2568VG-N
PerformanceParameter
2.4 – 2.5 GHz / 5.250 – 5.925 GHz
Frequency
6 dBi / 8 dBiGain
Linear, VerticalPolarization
22° / 11°E-Plane 3 dB Beamwidth
OmnidirectionalH-Plane 3 dB
Type N, fixed (male)RF Connector
1 WattPower
0.20 KgWeight
Polycarbonate, UV, grayRadome
-30°C to +70°COperational Temperature
Connector fixed, upright and inverted orientationMounting
38.1 diameter x 376.8 lengthDimensions (mm)
17
