5
4 Unpacking
To unpack the access point, follow these steps:
Step 1 Unpack and remove the access point and the accessory kit from the shipping box.
Step 2 Return any packing material to the shipping container and save it for future use.
Step 3 Verify that you have received the items listed below. If any item is missing or damaged, contact
your Cisco representative or reseller for instructions.
–
The access point
–
Mounting bracket (selected when you ordered the access point)
–
Adjustable ceiling-rail clip (selected when you ordered the access point)
5 Configurations
The 2600 series access point contains two simultaneous dual-band radios, the 2.4-GHz and 5-GHz
802.11n MIMO radios, in either controller-based mode (AIR-CAP2602 models) or standalone mode
(AIR-SAP2602 models). The 2600 series access point configurations are:
• AIR-CAP2602E-x-K9 and AIR-SAP2602E-x-K9—two 2.4-GHz/5-GHz dual-band radios with up
to 4 external dual-band dipole antennas
• AIR-CAP2602I-x-K9 and AIR-SAP2602I-x-K9—two 2.4-GHz/5-GHz dual-band radios, with
integrated dual-band inverted-F antennas
For information on the regulatory domains (shown as “x” in the model numbers) see “Regulatory
Domains” section on page 6.
External Antennas
The 2602E models are configured with up to four external dual-band dipole antennas, and two
2.4-GHz/5-GHz dual-band radios. The radios and antennas support frequency bands 2400–2500
MHz and 5150–5850 MHz through a common dual-band RF interface. Features of the external
dual-band dipole antennas are:
• Four RTNC antenna connectors on the top of the access point
• Three TX and four RX antennas
