Cisco ASR 9000 Series Configuration Manual

Configuring Serial Interfaces on the Cisco ASR 9000 Series Router
How to Configure Serial Interfaces
531
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
Configuring Optional Serial Layer 2 PVC Parameters
This task describes the commands you can use to modify the default configuration on a serial Layer 2
PVC.
Prerequisites
Before you can modify the default PVC configuration, you must create the PVC on a Layer 2
subinterface, as described in the “Creating a Serial Layer 2 Subinterface with a PVC” section on
page 529.
Restrictions
The configuration on both ends of the PVC must match for the connection to be active.
SUMMARY STEPS
1. configure
2. interface serial interface-path-id.subinterface l2transport
3. pvc dlci
4. encap [cisco | ietf]
5. service-policy {input | output} policy-map
6. fragment end-to-end fragment-size
7. fragment-counter
8. end
or
commit
9. Repeat Step 1 through Step 7 to configure the PVC at the other end of the AC.
10. show policy-map interface serial interface-path-id.subinterface {input | output}
or
show policy-map type qos interface serial interface-path-id.subinterface {input | output}
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/0RP0/CPU0:router# configure
Enters global configuration mode.
Step 2
interface serial interface-path-id.subinterface
l2transport
Example:
RP/0/0RP0/CPU0:router(config)# interface serial
0/1/0/0.1 l2transport
Enters serial subinterface configuration mode for a Layer 2
serial subinterface.
