2-25
Cisco ASR 9000 Series Aggregation Services Router Overview and Reference Guide
OL-17501-09
Chapter 2 Functional Description
Ethernet Line Cards
Figure 2-18 40-Port Gigabit Ethernet (40x1GE) Line Card Front Panel
1 Ejector lever (one of two) 5 Line Card Status LED
2 Port 0 SFP cage 6 Port 39 SFP cage
3 Port Status LED (one per port) 7 Port 1 SFP cage
4 Port 38 SFP cage 8 Captive installation screw (one of two)
242982
1
8
6
7
2
4
5
3
CLASS 1
LASER
3 5 7 9 11 13 15 17 19
10 12 14 16 18
21 23 25 27 29 20 22
31 33 35 37 30 3224 26 2868
A9K-40GE-E
STATUS
