Cisco ASR 9006 Installation Guide

Figure 155: Attaching the Air Deflectors on the Cisco ASR 9904 Router Chassis —Top View
12-24 screws for attaching
the air deflectors (two
screws per side)
3Top air deflector1
Bottom side stamp4Bottom air deflector2
Step 5 Secure the side air baffles to the air deflectors using the supplied 8-32 screws (Figure 156: Securing the Cisco
ASR 9904 Router Chassis Side Baffles to the Air Deflectors (Rear View), on page 149). Do not tighten the
screws.
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
148
Unpacking and Installing the Chassis
Installing Optional Air Baffles on the Cisco ASR 9904 Router
