Password: enablepass
Step 5
When your enable password is accepted, the privileged EXEC mode prompt appears: #
Step 6
You now have access to the CLI in privileged EXEC mode and you can enter the necessary commands to complete your
desired tasks. To exit the console session, enter the quit command as shown in the following example:
Example:
Router#quit
Configuring Global Parameters
When you first start the setup program, you must configure the global parameters. These parameters are used for controlling system-wide
settings. Perform the following steps to enter the global parameters:
Procedure
Step 1
Connect a console terminal to the console port, and then boot the router.
This is only an example of the output display; prompts may vary.Note
When you see this information, you have successfully booted your router:
Example:
Restricted Rights Legend
Use, duplication, or disclosure by the Government is
subject to restrictions as set forth in subparagraph
(c) of the Commercial Computer Software - Restricted
Rights clause at FAR sec. 52.227-19 and subparagraph
(c) (1) (ii) of the Rights in Technical Data and Computer
Software clause at DFARS sec. 252.227-7013.
cisco Systems, Inc.
170 West Tasman Drive
San Jose, California 95134-1706
.
.
.
--- System Configuration Dialog ---
Would you like to enter the initial configuration dialog? [yes/no]: yes
Press RETURN to get started!
Step 2
The first sections of the configuration script appear only at an initial system startup. On subsequent uses of the setup
facility, the script begins with a System Configuration Dialog as shown below. When asked if you would like to enter the
initial configuration dialog, enter yes.
Example:
Would you like to enter the initial configuration dialog? [yes/no] yes
At any point you may enter a question mark '?' for help.
Use ctrl-c to abort configuration dialog at any prompt.
Default settings are in square brackets '[]'.
25
