Cisco ASR-920-12SZ-IM User Manual

ASR-920-12SZ-IMSpecification
• 4 alarm dry contact inputs (normally open)
• LED indicators for critical, major, and minor alarms
Alarms
For more information on these IM modules, see the Cisco ASR 903 Aggregation Series Router
Hardware Installation Guide.
For more information on the supported IMs, see the Cisco ASR920 Data sheet.
Supported Interface Modules
• Front or rear rail 19 or 23 inches
• ETSI 300 mm open cabinet
• Wall mount
Mounting option
12x1G and 4x10G/1G portsPort Configuration
4x10G SFP+ – Port [12:15]
4x1G SFP – Port [8:11]
8x1G PoE RJ45/Cu ports [0:7]
Port Numbering
Ports 12 to 15 are Dual Rate portsCombo Ports
Link/Activity/FaultCopper/1G/10G Port LEDs
Four temperature sensorsTemperature Sensors
External ports for 1PPS/TOD1PPS/ToD
Provides power over EthernetPoE
Connects to the external GPSGNSS
5

Cisco ASR-920-12SZ-IM Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
USB ports quantity	2
Ethernet LAN (RJ-45) ports	8
Product color	Gray
Rack capacity	1U
Antenna type	Not supported
AC input voltage	100 - 240 V
Power source type	AC, DC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	130 W
Non-operating altitude	0 - 4570 m
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, 2005, CAN/CSA C22.2 No. 60950-1: 2005, IEC 60950-1, 2005, EN 60950-1, 2005, AS/NZS 60950.1:2005
Electromagnetic compatibility	FCC CFR47 Part 15 Class A
Mean time between failures (MTBF)	407230 h
Firewall	-
Security algorithms	IPSec

Weight and Dimensions

Depth	286.54 mm
Width	444.5 mm
Height	44 mm
Weight	4830 g
