Cisco ASR-920-24SZ-M User Manual

Suitable for mounting on and over a concrete or other non-combustible surface only. Statement 345Warning
Note
SUMMARY STEPS
1.
Mount the router with the front panel as shown in the following figures.
2.
Place the drip tray below the router as shown in the figure above.
3.
Tighten the four screws to affix the drip tray to the wall.
DETAILED STEPS
Step 1
Mount the router with the front panel as shown in the following figures.
Cisco ASR-920-24SZ-IM, ASR-920-24SZ-M, ASR-920-24TZ-M Aggregation Services Router Hardware Installation
Guide
63
Installing the Router
Mounting Routers on the Wall
