If the next packet arrives 0.40 seconds later, 400 bytes are added to the token buckets ((.40 * 8000)/8).
Therefore, the conform token bucket now has 1000 bytes (the maximum number of tokens available in the
conform bucket) and 200 bytes overflow the conform token bucket (because it only 200 bytes were needed
to fill the conform token bucket to capacity). These overflow bytes are placed in the exceed token bucket,
giving the exceed token bucket 300 bytes.
If the arriving packet is 1000 bytes, the packet conforms because enough bytes are available in the conform
token bucket. The conform action (transmit) is taken by the packet, and 1000 bytes are removed from the
conform token bucket (leaving 0 bytes).
If the next packet arrives 0.20 seconds later, 200 bytes are added to the token bucket ((.20 * 8000)/8). Therefore,
the conform bucket now has 200 bytes. If the arriving packet is 400 bytes, the packet does not conform because
only 200 bytes are available in the conform bucket. Similarly, the packet does not exceed because only 300
bytes are available in the exceed bucket. Therefore, the packet violates and the violate action (drop) is taken.
Additional References
Related Documents
Document TitleRelated Topic
Cisco IOS Quality of Service Solutions Command
Reference
QoS commands: complete command syntax,
command modes, command history, defaults, usage
guidelines, and examples
"Applying QoS Features Using the MQC" moduleModular Quality of Service (QoS) Command-Line
Interface (CLI) (MQC), hierarchical policies, policy
maps
"Policing and Shaping Overview" modulePolicing and shaping traffic
Standards
TitleStandard
--No new or modified standards are supported by this
feature, and support for existing standards has not
been modified by this feature.
MIBs
MIBs LinkMIB
To locate and download MIBs for selected platforms,
Cisco IOS XE software releases, and feature sets, use
Cisco MIB Locator found at the following URL:
http://www.cisco.com/go/mibs
No new or modified MIBs are supported by this
feature, and support for existing MIBs has not been
modified by this feature.
