Installing the Router Chassis in the Rack
Ensure adequate air flow when mounting the router in a rack. For more information, see the “Air Flow
Guidelines” section on page 11 .
Note
Install the cable guides before installing the router in a 19-inch EIA rack. See Attaching the Cable Guides.Note
To install the router chassis in the equipment rack, perform these steps:
SUMMARY STEPS
1.
Position the chassis in the rack as follows:
2.
Align the mounting holes in the bracket (and optional cable guide) with the mounting holes in the equipment
rack.
3.
Install the four M6x12mm zinc-plated steel screws through the holes in the bracket and into the threaded
holes in the equipment rack posts.
4.
Use a tape measure and level to verify that the chassis is installed straight and level.
DETAILED STEPS
Step 1
Position the chassis in the rack as follows:
•
If the front of the chassis (front panel) is at the front of the rack, insert the rear of the chassis between the mounting
posts.
•
If the rear of the chassis is at the front of the rack, insert the front of the chassis between the mounting posts.
Step 2
Align the mounting holes in the bracket (and optional cable guide) with the mounting holes in the equipment rack.
Cisco ASR 920 Series Aggregation Services Router Hardware Installation Guide
7
Installing the Cisco ASR 920 Series Router
Installing the Router Chassis in the Rack
