Disconnect the router console terminal before uninstalling the driver.
Note
SUMMARY STEPS
1. Choose Start > Control Panel > Add or Remove Programs.
2. Scroll to Windows Driver Package - Exar corporation (xrusbser) Ports and click Remove. The
Program Maintenance window is displayed.
3. Click Yes to uninstall the driver.
DETAILED STEPS
Step 1 Choose Start > Control Panel > Add or Remove Programs.
Step 2 Scroll to Windows Driver Package - Exar corporation (xrusbser) Ports and click Remove. The Program Maintenance
window is displayed.
Step 3 Click Yes to uninstall the driver.
Connect to the EIA Console Port
The US-to-RJ45 adapter cable and the DB9 console cable are not included with the router; they can be ordered
separately from Cisco.
Note
The serial console cable kit is not included with the router; it is ordered separately.
Note
To connect a terminal to the EIA Console port on the router, follow these steps:
Step 1 Connect the USB end of the USB-to RJ-45 cable to the EIA Console port.
Step 2 Connect the RJ-45 end of the DB-9 adapter cable to the USB-to RJ-45 cable, as shown in the figure below.
Installing the Cisco ASR 920 Series Router
30
Installing the Cisco ASR 920 Series Router
Connect to the EIA Console Port

Cisco ASR 920 series Specifications

General

Form Factor	1RU
Operating System	Cisco IOS XE
Model	ASR 920 series
Memory	4 GB DRAM
Power Supply	AC or DC
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Relative Humidity	5% to 95% non-condensing
MTBF	Varies by model
Management	CLI, SNMP
