Figure 4: System LED for a Cisco Catalyst 1000 Series Switch
Port LEDs2SYST LED (system)1
System LED
System StatusColor
System is not powered on.Off
System is operating normally.Green
System is receiving power but is not operating
properly.
Amber
POST is in progress.Blinking Green
Cisco Catalyst 1000 Series 8-Port and 16-Port Switch Hardware Installation Guide
7
Product Overview
System LED
