Cisco C1000-16T-E-2G-L User Manual

Smaller sleeve for thin
power cords
2
Step 4 Slide the retainer through the other latches to lock it.
Figure 23: Locking the Retainer
Latches3AC power cord1
Smaller sleeve for thin
power cords
2
Step 5 (Optional) Use the small sleeve for thin power cords. Use the small sleeve to provide greater stability for thin
cords. Detach the sleeve, and slide it over the power cord.
Figure 24: Sleeve Around the Power Cord
AC power cord2Smaller sleeve for thin
power cords
1
Step 6 Secure the AC power cord by pressing on the retainer.
Cisco Catalyst 1000 Series 8-Port and 16-Port Switch Hardware Installation Guide
31
Switch Installation
Installing the Power Cord Retainer (Optional)
