Cisco C1111x-8P

Figure 26: Cisco 11x1(X)-8P/ C11x1(X)-8PLTEP LED Indicators
PoE LED2VPN1
Ethernet switch ports 0-7 (0, 2, 4, 6 at the top
and 1, 3, 5, 7 at the bottom)
4Status3
GE 0/0/1 LED6GE 0/0/0 RJ45 LED5
Micro USB console LED8GE 0/0/0 RJ45 LED7
USB LED9
Figure 27: C1121(X)-8PLTEPWx LED Indicators
PoE LED2VPN1
Ethernet Switch Ports 0-7 (0, 2, 4, 6 at the top
and 1, 3, 5, 7 at the bottom)
4Status3
GE 0/0/0 RJ45 LED6Wi-Fi5
GE 0/0/0 SFP LED8GE 0/0/1 LED7
Micro USB console LED10USB LED9
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
15
Overview of Cisco 1000 Series Integrated Services Routers
LED Indicators
