Figure 2: Package Contents
RJ-45 to DB9-RS232 console cable (Cisco part
number 72-3383-XX)
2Chassis1
RJ-45 to RJ-45 Cat 5 Ethernet cable, yellow six
feet long (Cisco part number 72-1482-XX)
4Cisco rail kit (Cisco part number 800-43376-02)3
Two 1-Gb or 10-Gb SFP+ fiber optic transceivers
with cables
Supported on the C695F. You cannot
mix SFP transceiver types in the same
chassis. You can either have two 1-Gb
or two 10-Gb SFPs in the same
chassis.
Note
6Useful Links document
The steps in the Useful Links document send you
to the documentation you need to install, set up,
and configure your ESA appliance.
5
Serial Number Locations
The serial number (SN) for the ESA C195, C395, C695, and C695F is printed on the pullout asset card located
on the front panel as shown in the following figure.
Cisco Email Security Appliance C195, C395, C695, and C695F Hardware Installation Guide
4
Overview
Serial Number Locations
