Page #4 background imageLoading...
Page #4 background image
(Optional)
2
Cisco FlexStack-Plus module
4
14Connector
3
cover for redundant power system6
(Optional)
2 4
Cisco FlexStack cable15Cable guide7
(Optional)
2
Power cord retainer (PWR-CLP)16Four number-12 Phillips pan-head screws (48-0523-01)8
1
Catalyst 2960X-48FPD-L switch is shown for example. Your switch model might look different.
2
Item is orderable.
3
Item is only available for models that have an RPS port.
4
Item is available only for switches with a FlexStack-Plus port.
Running Express Setup
Before You Begin
When you first set up the switch, you should use Express Setup to enter the initial IP information. This enables the switch to connect
to local routers and the network. You can then access the switch through the IP address for further configuration.
To use the CLI-based initial setup program, see the switch hardware guide on Cisco.com.Note
You need this equipment to set up the switch:
A PC with Windows Vista, XP, or 2000 installed. Other laptops and browsers might work.
A web browser (Internet Explorer 5.5. 6.0, 7.0, Firefox 1.5, 2.0, and 3.0) with JavaScript enabled.
A straight-through or crossover Category 5 or 6 Ethernet cable.
Before running Express Setup, disable any pop-up blockers or proxy settings in your browser software
and any wireless client running on your PC.
Note
Procedure
Step 1
Make sure that nothing is connected to the switch.
3
