If the LED is off, the target device might not be turned on, there might be a cable problem, or there might be problem
with the adapter installed in the target device.
Connecting to 1000BASE-T SFP
When connecting to a 1000BASE-T device, be sure to use a four twisted-pair, Category 5 or higher cable.
The automatic medium-dependent interface crossover (auto-MDIX) feature is enabled by default. For
configuration information for this feature, see the switch software configuration guide or the switch command
reference on Cisco.com.
Note
To prevent ESD damage, follow your normal board and component handling procedures.
Caution
SUMMARY STEPS
1. Connect one end of the cable to the SFP module port. Insert a four twisted-pair, straight-through cable
when you connect to servers, workstations, and routers. Insert a four twisted-pair, crossover cable when
you connect to switches or repeaters.
2. Connect the other end of the cable to an RJ-45 connector on the other device.
3. Observe the port status LED.
4. If necessary, reconfigure and restart the switch or other device.
DETAILED STEPS
Step 1 Connect one end of the cable to the SFP module port. Insert a four twisted-pair, straight-through cable when you connect
to servers, workstations, and routers. Insert a four twisted-pair, crossover cable when you connect to switches or repeaters.
Step 2 Connect the other end of the cable to an RJ-45 connector on the other device.
Switch Installation
18
Switch Installation
Connecting to 1000BASE-T SFP
