Mid-mounting position3Front-mounting position1

Rear-mounting position4Number-8 Phillips flat-head screws2

Mounting a 24-Port or 48-Port Switch in a Rack

Step 1 Use the four supplied Phillips machine screws to attach the brackets to the rack.

Step 2 Use the black Phillips machine screw to attach the cable guide to the left or right bracket.

Figure 4: Mounting the Switch in a Rack

Number-12 Phillips pan-head screws

(48-0523-01) or Number-10 Phillips pan-head

screws (48-0627-01)

4Cable guide1

Mid-mounting position5Phillips machine screw, black (48-0654-01)2

Switch Installation

Mounting a 24-Port or 48-Port Switch in a Rack
