Attaching the Rack-Mount Brackets for the Catalyst 2960-X Switches
Procedure
Use two Phillips flat-head screws to attach the long side of the bracket to each side of the switch.
Figure 4: Attaching Brackets for 19-inch Racks
Mid-mounting position3Front-mounting position1
Rear-mounting position4Number-8 Phillips flat-head screws (48-2927-01)2
16
