The browser displays a warning message and tries to connect with the earlier switch IP address. Typically, connectivity
between the PC and the switch is lost because the configured switch IP address is in a different subnet from the IP
address on the PC.
For more information about Express Setup fields, see the online help for the Express Setup window.
Step 11
Disconnect the switch from the PC, and install the switch in your network.
Step 12
If you changed the static IP address on your PC in Step 2, change it to the previously configured static IP address.
Step 13
You can now manage the switch by using Cisco Network Assistant, Device Manager, or both. See Managing the Switch
for information about configuring and managing the switch. We strongly recommend that you download Cisco Network
Assistant from Cisco.com and use it to manage the switch.
You can display Device Manager by following these steps:
Start a web browser on your PC or laptop.
Enter the switch IP address, username, and password in the web browser, and press Enter. The Device Manager
page appears.
If Device Manager does not appear:
Confirm that the port LED for the switch port connected to your network is green.
Confirm that the PC or laptop you are using to access the switch has network connectivity by connecting to a
well-known web server in your network. If there is no network connection, troubleshoot the network settings
on the PC or laptop.
Make sure that the switch IP address in the browser is correct.
If the switch IP address in the browser is correct, the switch interface LED is green, and the PC or laptop has
network connectivity, continue troubleshooting by reconnecting the PC or laptop to the switch. Configure a
static IP address on the PC or laptop that is in the same subnet as the switch IP address. For example:
If your switch IP address is 172.20.20.85 and your PC or laptop IP address is 172.20.20.84, both devices
are in the same network.
If your switch IP address is 172.20.20.85 and your PC or laptop IP address is 10.0.0.2, the devices are in
different networks and cannot communicate directly.
When the LED on the switch port connected to the PC or laptop is green, reenter the IP address of the switch
in a web browser to display Device Manager. When Device Manager appears, you can continue with the switch
configuration.
Managing the Switch
After completing Express Setup and installing the switch in your network, you can use one of these options for further configuration.
7

Other manuals for Cisco Catalyst 2960-X

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco Catalyst 2960-X and is the answer not in the manual?

Cisco Catalyst 2960-X Specifications

General IconGeneral
Console portRJ-45
USB 2.0 ports quantity2
SFP module slots quantity4
Installed SFP modules quantity-
Gigabit Ethernet (copper) ports quantity48
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Power sourceAC
Input current5 A
AC input voltage100 - 240 V
Power consumption (typical)60.9 W
Number of power supply units1
Redundant power supply (RPS) supportYes
Operating altitude0 - 3000 m
Non-operating altitude0 - 4000 m
Storage temperature (T-T)-25 - 70 °C
Operating temperature (T-T)-5 - 40 °C
Operating relative humidity (H-H)10 - 95 %
Switching protocolsUDP, TCP, RADIUS/TACACS+
Number of VLANs1023
Networking standardsIEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput107.1 Mpps
Jumbo frames9216
Number of queues8
MAC address table16000 entries
Number of static routes1000
DHCP featuresDHCP server
AuthenticationMAC-based authentication, Port-based authentication
Security algorithms802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules3
Switch typeManaged
Switch layerL2/L3
SafetyUL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor1U
Product colorBlack
Total Power over Ethernet (PoE) budget370 W
Power over Ethernet (PoE) ports quantity24
Power over Ethernet plus (PoE+) ports quantity12
Memory typeDRAM
Noise level39 dB
Flash memory128 MB
Internal memory512 MB
Processor frequency600 MHz
Mean time between failures (MTBF)276870 h
Weight and Dimensions IconWeight and Dimensions
Depth368 mm
Width445 mm
Height45 mm
Weight5800 g
