Cisco Catalyst 2960-X Getting Started Guide

(Optional)
2
Cisco FlexStack-Plus module
4
14Connector
3
cover for redundant power system6
(Optional)
2 4
Cisco FlexStack cable15Cable guide7
(Optional)
2
Power cord retainer (PWR-CLP)16Four number-12 Phillips pan-head screws (48-0523-01)8
1
Catalyst 2960X-48FPD-L switch is shown for example. Your switch model might look different.
2
Item is orderable.
3
Item is only available for models that have an RPS port.
4
Item is available only for switches with a FlexStack-Plus port.
Running Express Setup
Before You Begin
When you first set up the switch, you should use Express Setup to enter the initial IP information. This enables the switch to connect
to local routers and the network. You can then access the switch through the IP address for further configuration.
To use the CLI-based initial setup program, see the switch hardware guide on Cisco.com.Note
You need this equipment to set up the switch:
•
A PC with Windows Vista, XP, or 2000 installed. Other laptops and browsers might work.
•
A web browser (Internet Explorer 5.5. 6.0, 7.0, Firefox 1.5, 2.0, and 3.0) with JavaScript enabled.
•
A straight-through or crossover Category 5 or 6 Ethernet cable.
Before running Express Setup, disable any pop-up blockers or proxy settings in your browser software
and any wireless client running on your PC.
Note
Procedure
Step 1
Make sure that nothing is connected to the switch.
3

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
