Cisco Catalyst 2960-X Getting Started Guide

Step 3
Replace the dust covers when you remove the FlexStack cables from the connectors.
Removing and installing the FlexStack cable can shorten its useful life. Do not remove and insert the cable
more often than is absolutely necessary.
Caution
Connecting to the Switch Ports
This section describes how to connect to the fixed switch ports and to the SFP module ports.
Connecting to the 10/100/100 or 10/100/1000 PoE+ Ports
The fixed ports on the Catalyst 2960-X or 2960-XR Power over Ethernet Plus (PoE+) switches provide:
•
PoE+ support for IEEE 802.3at-compliant powered devices
•
PoE support for IEEE 802.3af-compliant powered devices
•
Support for Cisco enhanced PoE (ePoE)
They also provide Cisco prestandard PoE support for Cisco IP phones and Cisco Aironet Access Points. See the switch hardware
guide for information on PoE budgeting. By default, a switch PoE port automatically provides power when a compliant device is
connected, including ePoE, PoE, and PoE+.
The automatic medium-dependent interface crossover (auto-MDIX) feature is enabled by default. The
switch detects the required cable type for copper Ethernet connections and configures the interfaces
accordingly. Therefore, you can use either a crossover or a straight-through cable for connections to a
copper 10/100/1000 module port on the switch, regardless of the type of device on the other end of the
connection.
Note
Procedure
Step 1
Insert a straight-through, twisted four-pair, Category 5 cable in a switch 10/100/1000 port when you connect to servers,
workstations, IP phones, wireless access points, and routers. Use a crossover, twisted four-pair, Category 5 cable when
you connect to other switches, hubs, or repeaters.
Step 2
Insert the other cable end into an RJ-45 port on the other device.
Connecting to SFP and SFP+ Module Slots
Some switch models have SFP module slots and others have SFP+ module slots. The SFP slots support only the SFP modules. The
SFP+ slots support both SFP and SFP+ modules. For a list of supported modules, see the release notes on Cisco.com. For detailed
instructions on installing, removing, and connecting to SFP modules, see the documentation that came with the SFP module.
20

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
