Cisco Catalyst 2960-X Getting Started Guide

Using Device Manager
The simplest way to manage the switch is by using Device Manager in the switch memory. This web interface offers quick configuration
and monitoring. You can access Device Manager from anywhere in your network through a web browser.
Procedure
Step 1
Launch a web browser on your PC or workstation.
Step 2
Enter the switch IP address in the web browser, and press Enter. The Device Manager page appears.
Step 3
Use Device Manager to perform basic switch configuration and monitoring. See the Device Manager online help for more
information.
Step 4
For a more advanced configuration, download and run Cisco Network Assistant, which is described in the next section.
Using Cisco Network Assistant
Cisco Network Assistant is a software program that you download from Cisco.com and run on your PC. It offers advanced options
for configuring and monitoring multiple devices, including switches, switch clusters, switch stacks, routers, and access points. Cisco
Network Assistant is free—there is no charge to download, install, or use it.
Go to this URL: http://www.cisco.com/en/US/products/ps5931/index.html
Procedure
Step 1
Click the Download Software link, and select the version that you want to download.
You must be a registered Cisco.com user, but you need no other access privileges.
Step 2
Find the Network Assistant installer.
Step 3
Download the Network Assistant installer and run it. (You can run it directly from the Web if your browser offers this
choice.)
Step 4
When you run the installer, follow the displayed instructions. In the final panel, click Finish to complete the Network
Assistant installation.
See the Network Assistant online help and the getting started guide for more information.
Using the Command-Line Interface
You can enter Cisco IOS commands and parameters through the CLI. Access the CLI by using one of these options.
8

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
