Removing a CFC or DFC3 Daughter Card
Figure 5 Partially Installing the Cap Nut
Step 8 With your left hand, lift slightly at the location shown in Figure 6. While lifting with your left hand, rock
the DFC3 daughter card up and down with your right hand, no more than half an inch in either direction,
to unseat the DFC3 daughter card from the module.
Cap nut
Appx 1/8 inch
120047
