Figure 25: Sliding the Retainer Clamp Through the Power Cord
Power cord retainer clamp2AC power cord connector1
Step 3 Insert the retainer strap through the latch at the bottom of the clamp and press the tabs on the retainer clamp
towards each other to secure the power cord.
Figure 26: Locking the Retainer Clamp
--Pressing the tabs on the
retainer clamp
1
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide
42
Installing a Compact Switch
Installing the Power Cord Retainer (Optional)

Cisco Catalyst 9200CX Compact Series Specifications

General

Model	Cisco Catalyst 9200CX Compact Series
Software	Cisco IOS XE
Power over Ethernet (PoE)	No
Stacking	Not supported
Weight	5.0 lb (2.3 kg)
Form Factor	Compact
Management	WebUI, CLI, SNMP, Cisco DNA Center
Power Supply	Internal power supply
Memory	4 GB DRAM
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to +70°C (-40°F to +158°F)
Relative Humidity	5% to 90% noncondensing
Ports	8, 12, or 24 10/100/1000BASE-T ports
Dimensions	1.73 x 10.5 x 9.45 in. (4.4 x 26.7 x 24 cm)
