Cisco Catalyst 9200CX Compact Series User Manual

Status (STAT) LED
Table 10: Status LED
System StatusColor
Status mode is disabled.Off
Status mode is enabled. Port LEDs function as
described in Port LEDs and Modes, on page 57.
Green
Speed LED
Link StatusLED Status
Speed mode is disabled.Off
Speed mode is enabled. Port LEDs function as described in Port LEDs and Modes, on page
57.
Green
PoE LED
The PoE LED indicates the status of the PoE mode: either PoE, PoE+ or UPOE.
Table 11: PoE LED
DescriptionColor
PoE mode is not enabled. None of the 10/100/1000 ports have been denied power
or are in a fault condition.
Off
PoE mode is enabled and Port LEDs function as described in Port LEDs and Modes,
on page 57.
Green
Port LEDs and Modes
Each Ethernet port has a port LED. These port LEDs, as a group or individually, display information about
the switch and about the individual ports. To select or change a mode, press the Mode button until the desired
mode is highlighted. When you change port modes, the meanings of the port LED colors also change.
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide
57
Switch LEDs
Status (STAT) LED

Cisco Catalyst 9200CX Compact Series Specifications

General

Model	Cisco Catalyst 9200CX Compact Series
Software	Cisco IOS XE
Power over Ethernet (PoE)	No
Stacking	Not supported
Weight	5.0 lb (2.3 kg)
Form Factor	Compact
Management	WebUI, CLI, SNMP, Cisco DNA Center
Power Supply	Internal power supply
Memory	4 GB DRAM
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to +70°C (-40°F to +158°F)
Relative Humidity	5% to 90% noncondensing
Ports	8, 12, or 24 10/100/1000BASE-T ports
Dimensions	1.73 x 10.5 x 9.45 in. (4.4 x 26.7 x 24 cm)
