C9300-NM-2Y Module

Table 4: C9300-NM-2Y Module with 25G SFP28 Module

ActionInterface

Configure this interfaceTwentyFiveGigabitEthernet1/1/1

Configure this interfaceTwentyFiveGigabitEthernet1/1/2

C9300-NM-8X Module

All ports in the C9300-NM-8X module default to 10 G and should be configured as TenGigabitEthernet1/1/1

through TenGigabitEthernet1/1/8, even when you are operating them as 1 G using SFP.

Table 5: C9300-NM-8-10X Module

ActionInterface

Configure this interfaceTenGigabitEthernet1/1/1

Configure this interfaceTenGigabitEthernet1/1/2

Configure this interfaceTenGigabitEthernet1/1/3

Configure this interfaceTenGigabitEthernet1/1/4

Configure this interfaceTenGigabitEthernet1/1/5

Configure this interfaceTenGigabitEthernet1/1/6

Configure this interfaceTenGigabitEthernet1/1/7

Configure this interfaceTenGigabitEthernet1/1/8

C3850-NM-4-1G Module

All ports in the C3850-NM-4-1G module are natively GigabitEthernet and are configured GigabitEthernet1/1/1

though GigabitEthernet1/1/4. There are only four interfaces that are valid, and the other four should not be

used even though they still show up in the CLI.

Table 6: C3850-NM-4-1G Module

ActionInterface

Configure this interfaceGigabitEthernet1/1/1

Configure this interfaceGigabitEthernet1/1/2

Configure this interfaceGigabitEthernet1/1/3

Configure this interfaceGigabitEthernet1/1/4

DisregardTenGigabitEthernet1/1/1

Installing a Network Module

C9300-NM-2Y Module
