Figure 8: Mounting the Chassis to the Rack
Cable guide installed2Screws to attach the chassis to the rack post1
Cable guide installation is complete.
Cisco Catalyst 9600 Series Switches Hardware Installation Guide
31
Installing the Switch
Installing the Cable Guide on the Chassis with L-Brackets Preinstalled on the Chassis
