4. Powering up the chassis and verifying the installation.
Install the Switch with Shelf Brackets
Installing the Shelf Kit L-Brackets
The switch chassis is shipped with two L-brackets installed on the front sides of the chassis. If you are
rack-mounting the switch using the shelf kit, these L-brackets must be removed and replaced with L-brackets
that are part of the shelf kit.
Before you begin
You have ordered and received the shelf kit.
Procedure
Step 1 Remove and discard the L-brackets and the ten mounting screws that the chassis is shipped with. Do not re-use
them during any part of the installation process.
Cisco Catalyst 9600 Series Switches Hardware Installation Guide
36
Installing the Switch
Install the Switch with Shelf Brackets
