Table 5: Port mapping for C9500-24Q
Configurable 10-Gigabit ports with Breakout Cable40-Gigabit native ports
1, 2, 3, and 41
5, 6, 7, and 82
9, 10, 11, and 123
13, 14, 15, and 164
17, 18, 19, and 205
21, 22, 23, and 246
25, 26, 27, and 287
29, 30, 31, and 328
33, 34, 35, and 369
37, 38, 39, and 4010
41, 42, 43, and 4411
45, 46, 47, and 4812
49, 50, 51, and 5213
53, 54, 55, and 5614
57, 58, 59 and 6015
61, 62, 63, and 6416
65, 66, 67 and 6817
69, 70, 71, and 7218
73, 74, 75, and 7619
77, 78, 79, and 8020
81, 82, 83, and 8421
85, 86, 87, and 8822
89, 90, 91, and 9223
93, 94, 95, and 9624
Cisco Catalyst 9500 Series Switches Hardware Installation Guide
13
Product Overview
Port Mapping for Cisco Catalyst 9500 Series Switches

Cisco Catalyst C9500-40X Specifications

General

Model	C9500-40X
Category	Switch
Product Series	Catalyst 9500
Rack Units	1 RU
Stacking	StackWise Virtual
Software	Cisco IOS XE
DRAM	16 GB
Flash Memory	16 GB
Input Voltage	100 to 240 VAC
Power Consumption	400W
Ports	40 x 10GE
Uplink Ports	4 x 40G/100G QSFP28
Forwarding Rate	1, 440 Mpps
Dimensions	1.73 x 17.5 x 21.52 in. (4.4 x 44.5 x 54.7 cm)
