Cisco Catalyst 9800-L Wireless Controller Front Panel
Figure 3: Cisco Catalyst 9800-L Wireless Controller Front Panel View
Table 2: Cisco Catalyst 9800-L Wireless Controller Front Panel Components
Service Port LED1
Redundancy Port LED2
Service Port (SP) (RJ-45) for out-of-band management3
Redundancy Port (RP) (RJ-45).
The redundancy ports can be connected
back to back or via an L2 switch.
Note
4
