Cisco Catalyst C9800-L User Manual

CHAPTER 3
Installing the Cisco Catalyst 9800-L Wireless
Controller
This chapter describes how to install the Cisco Catalyst 9800-L Wireless Controller.
IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work
on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard
practices for preventing accidents. Use the statement number provided at the end of each warning to locate
its translation in the translated safety warnings that accompanied this device. Statement 1071
Warning
SAVE THESE INSTRUCTIONS
• Mounting the Controller, on page 13
• Connecting the Controller Console Port, on page 24
• Management Ethernet Port Cable Connection, on page 24
• Installing a Security Lock, on page 25
Mounting the Controller
This section describes the various mounting options for the controller:
Mounting the Controller on Desktop or Shelf
Before mounting the controller on a desktop or shelf, install the rubber feet located in accessory kit shipped
with the controller.
To install the rubber feet to the controller, follow these steps:
Procedure
Step 1 Locate the rubber feet on the black adhesive strip that is shipped with the controller.
Cisco Catalyst 9800-L Wireless Controller Hardware Installation Guide
13

Cisco Catalyst C9800-L Specifications

General

Category	Controller
Console Port	1x RJ-45
Throughput	5 Gbps
Operating System	Cisco IOS XE
Rack Height	1RU
Humidity	5% to 95% non-condensing
Model	Cisco Catalyst C9800-L
Management Ports	1 x 1G RJ-45
USB Ports	1 x USB 3.0
Redundancy	N+1
Wireless Standard	802.11ax, 802.11ac
Power Supply	AC or DC
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-40°C to 70°C
Encryption	AES
