Cisco CBS Series User Manual

Hybrid stackCBS350 “10G network port
SKUs”
CBS350 “10G uplink port
SKUs”
Feature
Per SKU typeNot supportedSupported on specific
SKUs
PoE support
0320Default number of VLAN
Mapping entries
On VLAN 1On OOBOn VLAN 1Default IP address
•
Power over Ethernet Considerations
Some switches support PoE while others do not. The switch models that support PoE have a P in their model
number, such as: CBSxxx-xxP-xx. If your switch is one of the Power over Ethernet (PoE) models, consider
the following power requirement.
The switch is to be connected only to PoE networks without routing to the outside plant.
Warning
Table 1: Switches with Power Over Ethernet
PoE PSE SupportPoE PD Chipset TypeDescriptionSKU Name
AF/AT1*69208M8-Port 2.5G PoE Managed
Switch
CBS350-8MGP-2X
AF/AT1*69208M8-Port 2.5G PoE
Stackable Managed
Switch
CBS350-8MP-2X
AF/AT/60W1*69208M + 1*6920424-Port 2.5G PoE
Stackable Managed
Switch
CBS350-24MGP-4X
AF/AT/60W3 * TPS238812-Port 5G PoE Stackable
Managed Switch
CBS350-12NP-4X
AF/AT/60W4* TPS238824-Port 5G PoE Stackable
Managed Switch
CBS350-24NGP-4X
AF/AT
/60W
7* TPS238848-Port 5G PoE Stackable
Managed Switch
CBS350-48NGP-4X
AF/ATTPS23888-Port Gigabit PoE
Managed Switch
CBS350-8P-2G
AF/ATTPS23888-Port Gigabit PoE
Managed Switch
CBS350-8P-E-2G
Get To Know Your Switch
7
Get To Know Your Switch
Power over Ethernet Considerations

Cisco CBS Series Specifications

General

Category	Switch
Port Speed	10/100/1000 Mbps
Operating Temperature	0°C to 45°C (32°F to 113°F)
Dimensions	Varies by model
Weight	Varies by model
Series	CBS Series
Management	Web-based, CLI
Layer	Layer 2
PoE	Available on some models (PoE and PoE+)
Uplink	SFP
Mounting	Desktop or rack-mountable
Switching Capacity	Varies by model
Forwarding Rate	Varies by model
VLAN Support	Yes
QoS	Yes
Security Features	ACLs, 802.1X authentication, Port Security
Management Interface	Web GUI
MAC Address Table Size	Varies by model
Jumbo Frame Support	Yes
Energy Efficiency	Energy Efficient Ethernet (EEE)
Ports	Varies by model (8, 16, 24)
