Chapter 2 Installation
Installing the Router
2-10
Cisco 837 Router and SOHO 97 Router Hardware Installation Guide
78-14781-02
Perform the following steps to mount the router on the wall:
Step 1 Secure two screws 7 5/8 inches (19.35 cm) apart into a wall and 1/8 inch (0.32 cm)
from the wall.
Step 2 Hang the router on the screws as shown in Figure 2-3.
Step 3 Place the power supply on a horizontal surface.
Installing the Router
To install the router, you need to perform the following tasks in the following
order:
1. Connect the Ethernet devices to the router.
2. Connect the ADSL line.
3. Connect a terminal or PC to the router for software configuration using the
command-line interface (CLI) or for troubleshooting.
4. Connect the router to the power source.
5. Verify the links, using the router LEDs.
1 Two number-six, 3/4-in.
screws
5 Maximum distance between the
router and the power supply
(6 ft [1.8 m])
2 Distance between the two
screws (7 5/8 in. [19.35 cm])
6 Horizontal surface for placing
the power supply.
3 Cisco 837 router 7 Distance between the screw and
the wall (1/8 in. [0.32 cm]).
4 Mounting brackets
