Appendix A Specifications and Cables
Port Connector Pinouts
A-2
Cisco 837 Router and SOHO 97 Router Hardware Installation Guide
78-14781-02
For information on regulatory compliance, refer to the Regulatory Compliance
and Safety Information for Cisco 800 Series and SOHO Series Routers document
that shipped with your router.
Warning
Ultimate disposal of this product should be handled according to all national
laws and regulations.
Port Connector Pinouts
This section provides pinouts for the following connectors:
• Console (for connecting a terminal or PC)—See Table A-2.
• ADSL—See Table A-3.
Router Power
AC input voltage 100 to 240 VAC
Frequency 50 to 60 Hz
Power consumption Maximum of 18W
Voltage 18 VDC
Table A-1 System Specifications (continued)
Description Design Specification
Table A-2 Console Connector Pinouts (RJ-45)
Pin Function
1RTS
2DTR
3TXD
4GND
5GND
6RXD
