Cisco 837 Router and SOHO 97 Router Hardware Installation Guide
78-14781-02
Appendix A Specifications and Cables
Port Connector Pinouts
The console port is configured as a data communications equipment (DCE)
device. The default parameters for the console port are as follows:
• 9600 baud
• Eight data bits
• No parity
• One stop bit
Table A-3 shows ADSL connector pinouts for the Cisco 837 and SOHO 97
routers.
7DSR
8CTS
Table A-2 Console Connector Pinouts (RJ-45) (continued)
Pin Function
Table A-3 ADSL Connector Pinouts (RJ-11)
Pin Function
1 Loopback to pin 6
2Unused
3Tip
4Ring
5Unused
6 Loopback to pin 1
