Chapter 2 Installation
Installing the Router
2-12
Cisco 837 Router and SOHO 97 Router Hardware Installation Guide
78-14781-02
Figure 2-3 Connecting a Server, PC, or Workstation to the Router
1 Cisco 837 router 4 PC
2 Yellow Ethernet cable 5 RJ-45 port on the network
interface card (NIC)
3 Ethernet port 4
ETHERNET
4
3
2
1
Cisco 837
ADSL
CONSOLE
82001
2
4
1
3
5
