Cisco 837 Router and SOHO 97 Router Hardware Installation Guide
78-14781-02
Chapter 2 Installation
Installing the Router
Figure 2-7 Connecting the Console Port to an Async Modem
1 Cisco 837 router 4 Wall jack
2 Console port 5 Telephone
3 Available port on an async
modem
