Cisco CMX 3375 User Manual

Figure 1: Cisco CMX 3375 appliance (SFF Drives) Front Panel
Fan status LED7Drive bays 1 – 10 support SAS/SATA hard disk
drives (HDDs) and solid state drives (SSDs)
1
Network link activity LED8Drive bays 1 and 2 support SAS/SATA and NVMe
PCIe solid state drives (SSDs)
2
Temperature status LED9Power button/power status LED3
Pull-out asset tag10Unit identification button/LED4
KVM connector
(used with KVM cable that provides one DB-15
VGA, one DB-9 serial, and two USB connectors)
11System status LED5
-Power supply status LED6
Cisco CMX 3375 appliance Rear Panel Features
The rear panel features are the same for all versions of the Cisco CMX 3375 appliance.
For definitions of LED states, see Rear-Panel LEDs, on page 6.
Cisco 3375 Appliance for Cisco Connected Mobile Experiences Installation Guide
2
Overview
External Features

Cisco CMX 3375 Specifications
